B-CUBE H743 Flight Controller

Note:Set Yaw as 270

Use betaflight firmware app from here, https://app.betaflight.com/#

Features:
1. The H743 is a 3-6S 36x36mm mini flight controller with a 16MB Blackbox flash memory, 5V 10V dual BEC. Designed for easy maintenance and low interference.
2.  The PCB adopts high-end composite material, which has stronger overcurrent capability and good heat dissipation. MOS adopts imported high current resistance mos, low energy consumption, long life and strong load capacity.
3. Using industrial grade LDO, high temperature resistance. High-quality capacitors, strong filtering performance.
4. Intelligent control: The controller has a built-in low-noise button, which can be controlled remotely by one button.
5. Maximum power: The OSD allows you to control your drone with maximum speed and accuracy, while providing a smoother flight.

Specifications:

• Chip:STM32H743VIT6(480MHZ)
• Gyro:BMI270 *2
• Barometer:SPL06-01
• OSD Chip:AT7456E
• Black box:16MM
• LED Program:Support
• BB buzzer:Support
• Input voltage:3-6S
• I2C Connector:Support
• BEC:5V/2.5A
• BEC:10V/2.0A
• Cam Input:Support
• USART:UART1,UART2.UART3.UART4.UART6.UART7
• Receiver:ELRS(CRSF).TBS(CRSF).SBUS.IBUS.DSM2.DSMX
• GPS:YES
• COMPASS:YES
• HD O3:YES
• ESC Signal:Dshoot150.Dshot300,Dshot600
• USB:TYPE-C
• Current Port:Yes.
• Voltage Sensor:Yes
• Firmware: cleanflight/betaflight/inav/ardupilot
• FC firmware:5.5_STM32H743_JHEH743_HD.hex/ inav_9.0.1_JHEMCUH743HD.hex / arducopter4.6_with_bl.hex
• Installhole:30.5*30.5*4MM
• Board size:36*36MM
• Weight:7.9g
